YZ23B Synoptophore with Table
Combine diagnosis, treatment, simultaneous viewing, syncretic viewing, solid viewing, and afterimage in one machine
A pair of haidingers brush
20 pairs cards with different angle
Advanced semi-transparent and semi- reflecting viewfinder
Durable LED luminophor
Manual or automatic coruscation are optional
Specifications
Magnification: | 1.65X |
Diameter of visual field: | More than 56MM |
Red light wavelength: | λ=640nm |
Left and right tubes around erect axis: | Concourse 50°, radiation 40° |
Left and right tubes around horizontal axis: | ±30° |
Pictures of left and right can be moved up and down according axis: | ±10△ |
Pictures of left and right can be moved up and down around optical axis: | ±20° |
Adjustable PD range: | 45mm to 75mm |
Darkroom illumination: | LED luminophor with symmetry design |
Adjustable haidingers brush: | 50 to 100 round/min |
Coruscation form: | Manual or Auto |
Automatic coruscation frequency: | Ten-step, 30300 times/min |
Range of automatic coruscation (each cycle): | 1/4 on 3/4 off, 1/2 on 1/2 off, 3/4 on 1/4 off |
Type of automatic coruscation: | The left and right can be turned on or off at the same time. The left and right can be turned on or off alternatively. One on and the other off. One on or off while the other can be turned on or off. |
Whole packing volume: | 0.425 CBM |
Carton number: | 2 cartons |
Total weight: | 61kgs |
